Agrimaster R520
.opt.webp)
1.25m
90HP+
T Flail
Agrimaster R520
Weaving Machinery has been the official UK stockist of
Agrimaster equipment for over 25 years. The range of flail mowers and hedge
cutters is robust and reliable and with a wide range of models to choose from,
there is a machine to suit every operator.
All new Agrimaster equipment is sold with a year’s warranty.
Weaving Machinery stock, a full complement of spare parts for the range,
available on next day delivery for most UK addresses.
The Agrimaster R520 is an entry level hedge cutter for the
small to medium size farmer with a heavy-duty construction and simple joystick
cable controls.
Standard Specification
Fully proportional electric joystick controls, cable rotor engagement, rotor reverse, parallel arm, head float, power slew with break back, storage legs. 200L oil tank with oil. 58HP. T flails, lights, 3 belt drive head.
Includes 1 year warranty
Agrimaster R520 Key Features
Operator Friendly Features
Complete with a 65HP hydraulic pump and 200L oil tank, the R520 has a fully independent hydraulic system driven by PTO. The parallel arm system allows movement towards and away from the tractor without altering the height or angle of the head. The hydraulic breakback works in conjunction with power slew giving the ability to bring the arm behind the tractor for a narrow transport width. Head float allows the cutting head to self-level during operation, following the contours of the ground.
Dual Direction Rotor/Cutting Head
An independent hydraulic system allows for dual direction cutting. Through a lever on the cable controls, you can switch the rotor direction which allows reverse drive for grass or hedges. The head is belt driven to provide extra protection for the hedge cutter.
Electric Controls
Our new electric joystick controls are now fitted as standard, bringing the main operating functions together in one compact, clearly labelled unit. The joystick and slide switches provide convenient adjustment of the arm and cutting head, with dedicated rotor controls and a prominent emergency stop button. The straightforward layout keeps controls close to hand for simple, comfortable operation throughout the working day.
Product Videos
Pricing
Enquire about PricingProduct Titles
Finance Calculator
Enquire about FinanceTechnical Specification
| Model | R520 / 125 |
|---|---|
| Working width (m) | 1.25 |
| Weight (kg) | 1105 |
| PTO | 540 |
| No. of flails | 20 |
| No. of belts | 3 |
