Shortdisc
Whether a
minimum tillage or conventional farming system, the Weaving ShortDisc offers
itself as a great multipurpose tool that can be used for chitting weed-seeds
and volunteers into stubble, incorporating organic matter or creating a stale
seedbed. Due to its functional versatility and heavy-duty
design, the Weaving ShortDisc can save machinery, fuel and labour costs per
hectare without compromising on yield or quality.
The
configuration of the front cutting discs followed by the full width roller
allows the ShortDisc to effectively chop through any harvest crop residue, then
leave an even stale seedbed.
This fast and effective
cultivator can be fitted with a Weaving Magnum Seeder and splash plate
arrangement allowing it to drill cover crops, small seeds and oil seed rape at
a low cost.
The ShortDisc is available
in 3 – 6 metre working widths, all in a mounted format.
Standard Specification
2 Rows of 560mm Ø concave discs mounted on rubber shock
absorbers, side boards and a full width 700mm Ø heavy duty 'V' ring packer
roller. Hydraulic Depth Control with coloured spacer adjustment. Hydraulic
transport safety lock for folding models.125mm disc spacing with individually
mounted arms.
Includes 1 year warranty
Key Features
Multipurpose Cultivator
The Shortdisc is a universal cultivator suitable for a range of farming systems. Depending on setup, it can be used for creating a chit into stubble, incorporating manure and residues, preparing a seedbed ready for drilling and establishing cover crops and small seeds.
Concave Discs with Sealed for Life Bearings
The Shortdisc is fitted with discs mounted on rubber torsion bars providing maintenance free, effective suspension. Each individual arm only carries 1 disc improving ground contouring and penetration. A large distance between the disc and the frame of the machine and between each leg ensures adequate clearance for material to flow through. The concave discs are fitted to each arm using a ‘Sealed for Life’, maintenance free Agrihub bearing offering permanent lubrication.
Hydraulic Depth Control
The working depth of the ShortDisc is between 0 and 15cm (6”), and is easily adjusted using the hydraulic operated rear roller. The hydraulic rams are extended, and aluminium spacers inserted to set the desired working depth.
Heavy Duty Cast Iron Roller
A 700mm British Cast Iron ‘V’ ring packer roller follows the 2 rows of discs to leave a firm and level seedbed. The roller is equipped as standard with easily detachable clod breakers allowing for quick replacement or for clearing large debris. The cast rings are made up of 3 individual pieces also for ease of replacement if needed.
Trailed Shortdisc
Building on the success of our mounted Shortdisc, from Autumn 2023 we are taking orders for a trailed model. The trailed Shortdisc offers greater maneuverability and more balanced weight distribution leaving a lighter footprint and requiring less horsepower. The rear transport wheels are lifted when in work.
Discs
The Weaving Shortdisc comes as standard with a choice of 3 discs with their own unique properties. The bulldog disc is for shallow tillage and creating a chit of weeds, the scalloped disc for deeper mixing of residues and the intermediate disc is inbetween the two offering shallow tillage with a increased mixing effect.
Ultra Low Disturbance Finance
At Weaving Machinery, we understand that new asset purchases can be tough on cashflow especially before harvest. So to help make our tillage equipment more affordable to out customers, we are excited to offer 0% hire purchase plans on both the LD Top-Soiler and the Shortdisc. These finance plans can be structured in two ways. Finance must be activated before 30th September 2024. The hire purchase plans are subject to eligibility, see the terms and conditions below.
See Terms & ConditionsProduct Videos
Gallery
Pricing
Product Title Prices
Optional Specification
Select from the options below to add them to the final price
Seeder Kit 6m
£12,800
Technical Specification
| Model | 3000M | 4000M | 5000M | 6000M | 5000T | 6000T | 12000T |
|---|---|---|---|---|---|---|---|
| Working width (m) | 3 | 4 | 5 | 5.8 | 5 | 5.8 | 12 |
| Transport width (m) | 3 | 2.7 | 2.7 | 2.7 | 2.7 | 2.7 | 2.97 |
| Number of discs | 22 | 32 | 40 | 44 | 40 | 44 | 88 |
| Disc spacing (mm) | 125 | 125 | 125 | 125 | 125 | 125 | 125 |
| Disc diameter (mm) | 560 | 560 | 560 | 560 | 560 | 560 | 560 |
| Recommended working speed (kph) | 10-20 | 10-20 | 10-20 | 10-20 | 10-20 | 10-20 | 10-20 |
| Min power requirement (hp) | 130 | 160 | 200 | 250 | 200 | 250 | 250+ |
| LED road lights | Standard | Standard | Standard | Standard | Standard | Standard | Standard |
| Packer diameter (mm) | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Row spacing (m) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Working depth (mm) | 0-150 | 0-150 | 0-150 | 0-150 | 0-150 | 0-150 | 0-150 |
| Weight (kg) | 1900 | 2600 | 3100 | 3500 | 5330 | 5750 |
Testimonials
Will Duchesne, M & W Duchesne, Suffolk
Seeing
how things are changing in agricultural and the rising costs associated with
growing crops, I knew a change was required. I decided to opt for shallower
tillage and reducing costs whilst not compromising on crop output.
Our
previous system involved ploughing and minimum tillage up to a 10” tine depth,
using a 3-metre mounted min-till cultivator. We’ve replaced this with the
Weaving Sabre Drill and the Weaving ShortDisc, both 6 metres and this has done
us very well, halving our fuel consumption and man hours.
The
addition of the 12-outlet Weaving Magnum Seeder, makes the ShortDisc very
versatile and so far, we've used it for sowing cover crops but we will also use
it for OSR and grass seeds. I’m very pleased with how the seeder is mounted to
the ShortDisc and its design; the Accord type metering unit allows a larger
scope of seed types to be used and it has a good size hydraulic fan.
The
6 metre ShortDisc is heavy and takes a bit of lifting, I’m using a 215 HP John
Deere, but owing to its high work rate its allowed a significant reduction in
diesel consumption per hectare whilst still creating a good tilth for a sterile
seedbed and to help cover the seed at drilling.
